Introduction

Current endoscopic ultrasound technologies (EUS) are suboptimal in the assessment of pancreatic cystic lesions (PCLs). We developed a new through-the-needle brush, the "loop brush", to improve the cellular yield, and thereby sensitivity, of EUS fine needle aspiration (EUS-FNA) of pancreatic cysts.

Aims & Methods

We aim to evaluate the "loop brush" safety, robustness, and efficacy.
We performed an in-vivo randomized controlled trial in pigs using artificial cysts. In one group, the loop brush was deployed through a 22G EUS-FNA needle into the cysts. In the control group, cystic punction was performed with standard EUS-FNA. Loop brushes were visually inspected post-procedure. Cytological assessment, cell counting, and hemoglobin analysis were performed in samples from both groups.

Results

Artificial cysts (n=114) were punctured in six pigs, 57 in each group. Neither adverse events nor significant device malfunction occurred during loop brushing. Samples collected with the brush had non-detectable concentrations of hemoglobin in 72% (41/57) of cases, and 26% (16/57) had less than 0.6 g/dL, with no significant difference to the controls (p=0.32). Brushing cell counts were associated with significantly increased cell counts (11.7× median difference, p<.0001). Cytological smears
were diagnostic in 77% of cases in the brushing group, while 54% in the control group (p=0.01, Fisher’s exact test; p=0.006, Chi-square test).

Conclusion

The new loop brush procedure appears to be safe, causing neither significant bleeding nor device malfunction. Samples obtained with the loop brush were suitable for cytological analysis and showed significantly higher cell yield than controls. Further clinical studies are warranted.

References

DOI: 10.1053/j.gastro.2020.10.007
DOI: 10.1186/s12916-018-1215-3
DOI: 10.3389/fonc.2021.688377
DOI: 10.1136/gutjnl-2016-313127
DOI: 10.1038/ajg.2018.14
Mohamed, E.; et al. Role of radiological imaging in the diagnosis andcharacterization of pancreatic cystic lesions: a systematic review. Pancreas 2018, 47, 1055–1064.
Cazacu, I. M.; et al. A quarter cen- tury of EUS-FNA: Progress,milestones, and future directions. Endoscopic ultrasound 2018, 7, 141
DOI: 10.1038/s41598-021-81065-2
doi: 10.4103/eus.eus_93_17
Shirley, L. A.; et al. Routine cyst fluid cytology is not indicated in the evaluation of pancreatic cystic lesions. Journal of Gastrointestinal Surgery 2016, 20, 1581–1585.
Muniraj, T.; et al. Devices for endoscopic ultrasound-guided tissue acquisition. Techniques in Gastrointestinal Endoscopy 2018, 20, 2–9.
Balaban, V. D.; et al. EUS- through-the-needlemicrobiopsy forceps in pancreatic cystic lesions: A systematic review. Endoscopic Ultrasound 2021, 10, 19.
Marques, F.; et al. A loop-shaped minimally invasive brush for improved cytology sampling of pancreatic cysts during EUS-FNA. Medical Devices & Sensors 2021, 4, e10165.
doi: 10.1177/0271678X20943823.
doi: 10.3748/wjg.v18.i34.4659
DOI: 10.3748/wjg.v27.i26.4194

Disclosure

FM, WW, UA, NR, and FBS have patent applications for the brush technology and are co- founders of Lucky LoopMedical AB, a company commercializing technology for improved sampling in EUS-FNA. UA has received a research grant from Boston Scientific and is a consultant to Boston Scientific, Medtronic, and Ambu. IS declares no conflict ofinterest.
