Introduction

Endoscopic retrograde cholangiopancreatography (ERCP) techniques have advanced exponentially in recent years. However, ERCP is often challenging to complete, and one factor is the difficulty of the selective approach to the bile ducts, including the cystic duct, biliary stenosis, or postoperative anastomosis. We newly developed and commercialized a wire-driven bidirectional steerable catheter using artificial blood vessel material for ERCP, including these difficult cases. In this study, we evaluated its usefulness and safety in approaching the biliary tract using a desktop phantom in patients with surgically altered anatomy of Roux-en-Y hepaticojejunostomy.

Aims & Methods

The developed novel catheter uses a seamless tube that comprises a body part with polytetrafluoroethylene (PTFE) and a 15mm long distal part with porous expanded PTFE. The minimum tube diameter is 2.1 mm, and the distal tip diameter is 1.4 mm. Two loop-formed control wires are installed into the tube for bidirectional bending. A desktop experiment compared the bending performance via a balloon-assist enteroscopy and the trackability with a conventional catheter with a steerable tip. In addition, we clinically evaluated the success rate and duration of selective cannulation for the biliary branch and the frequency of complications in the four patients who underwent intestinal tract reconstruction by Roux-en-Y cholangiojejunostomy and required endoscopic treatment for symptoms such as acute cholangitis.

Results

The developed steerable catheter could bend over 90 degrees in both directions, and the minimum bending radius was about 4 mm, approximately five times smaller than the conventional steerable catheter. The desktop phantom trackability tests showed that using the developed steerable catheter and a guidewire enabled physicians to select bile duct branches with complex and steep angles easily and quickly. In the clinical evaluation, the insertion of the guide wire and the developed steerable catheter was swiftly completed in the bile ducts bilaterally in the patients, which was impossible with the conventional steerable catheter. The mean time required for guide wire insertion in the unilateral bile duct was 18.8 ± 10.1 seconds with the steerable catheter and 94.1± 42.1 seconds with the conventional catheter (p < 0.05). No catheter-related complications occurred.

Conclusion

The newly developed catheter with a steerable tip showed high bending performance compared to the conventional catheter. It was applied to complex diversion of the biliary branch for ERCP, especially in patients with surgically altered anatomy.

Introduction

Endoscopic retrograde cholangiopancreatography (ERCP) with endoscopic sphincterotomy (EST) is an established endoscopic treatment for common bile duct stones and acute cholangitis. Due to its less invasiveness compared to surgery, it has been accepted as a first choice even for the elderly receiving anticoagulants. However, there is only a limited number of reports of the safety of EST after minimal cessation of anticoagulant based upon the Japan Gastroenterological Endoscopy Society (JGES)guideline.

Aims & Methods

To evaluate the safety, we aimed to clarify the bleeding risk in patients taking anticoagulants in our institute. Patients who underwent ERCP at double institutes from January 2018 to December 2021. Among them, we compared the rate of bleeding after EST and bleeding requiring blood transfusion in anticoagulant patients and non-administrators. Patients taking anticoagulants were allowed to discontinue the direct oral anticoagulant (DOAC) on the day before or the day of ERCP, and those who followed the JGES guideline for warfarin were included.

Results

ERCP was performed in 1616 patients and an analysis of a total of 882 patients of EST including 69 patients taking anticoagulants revealed that there were no significant differences in the bleeding rate although the blood transfusion rate was significantly higher in the DOAC group (2/52 3.9%) and antiplatelet drug combination cases (1/15 6.7%) compared to other cases (5/805 0.6%). Univariate and multivariate analyzes were performed according to background age, sex, hypertension, diabetes mellitus, heart disease, cerebrovascular disease, hemodialysis, platelet count decreased (less than 10x10⁴/μL), and urgency (within 24 hours after consultation). In the univariate analysis for EST bleeding, cerebrovascular disease, hemodialysis, and thrombocytopenia were significant risk factors(p<0.05). As a result of the multivariate analysis of these, only cerebrovascular disease was a significant risk factor (OR=2.11, 95%CI: 1.21-3.68, p=0.0086). In the univariate analysis for blood transfusion, DOAC users, cerebrovascular disease, and hemodialysis patients were significant risk factors(p<0.05). A multivariate analysis that added EST bleeding to these results also found significant risk factors for similar items. DOAC(OR=6.89, 95%CI: 1.06-44.65, p=0.043) and cerebrovascular disease(OR=18.85, 95%CI: 3.01-117.93, p=0.0017), hemodialysis(OR=55.68, 95%CI: 6.51-475.99, p=0.00024) were significant risk factors for severe bleeding requiring blood transfusion.

Conclusion

Although there were no significant differences between the bleeding rates of EST for those taking anticoagulants and those not taking anticoagulants, it was suggested that there is a possibility of serious bleeding requiring blood transfusion in patients receiving anticoagulants, especially DOAC.

Disclosure

none

Introduction

The ulcers after duodenal endoscopic resection (ER) are exposed to bile and pancreatic juice, therefore delayed perforation and bleeding are common. As a preventive measure, the suture of the ulcer after ER has been reported to be effective. Our data are shown as follows. From January 2007 to January 2018, ER was performed for 219 duodenal tumors. We compared 211 lesions in the suture group with 8 lesions in the non-suture group. Delayed perforation was 0% in the suture group and 13% (1/8) in the non-suture group, showing a significant difference (p=0.0365). Delayed bleeding was 1% (3/211) in the suture group and 25% (2/8) in the non-suture group, showing a significant difference (p=0.01). Therefore, the suture of the ulcer after ER is essential. If the ulcer is small after ER, it can be sutured endoscopically, but if it exceeds 3 cm, it is difficult to suture with the endoscope alone.

Aims & Methods

The aim of this study is to investigate the outcome of duodenal laparoscopic and endoscopic co-operative surgery (D-LECS) for superficial non-ampullary duodenal epithelial tumors (SNADETs).
First, tissue around duodenum is dissected laparoscopically. Second, endoscopic submucosal dissection (ESD) is performed using saline injection, Hook knife, and VIO 300D or VIO3. Sites with poor maneuverability endoscopically were resected with laparoscopic assistance. Third, ulcer after ER is sutured laparoscopically. If inadequate, endo clip is added.
Thirty-five patients with SNADETs who underwent D-LECS from January 2014 to March 2023 were investigated outcome of procedure. The patient’s characteristics were as follows. male/female: 23/12, median age 65 (37-83) years old, location of the tumor (bulbs/2^nd/3rd portion): 3/27/5, major macroscopic type (0-I/0-IIa/0-IIc): 1/29/5. pancreatic side/ non-pancreatic side of duodenum: 26/9.
SM1 was defined as submucosal invasion of less than 500 μm, and SM2 was defined as deeper. R0 was defined as lateral and vertical margin negative, and lymph-vascular involvement negative. Median follow-up period was 13 (0-42) months.

Results

1. Median procedure time was 351 (195-673) minutes. In it, median endoscopic procedure time and laparoscopic procedure time were 205(132-429) and 131(67-420) minutes, respectively. Median diameter of resected specimen and tumor were 40 (26-70) and 27 (14-53) mm, respectively. Intramucosal tumor (Vienna classification category 3 to 5.1) /T1bSM2 (category 5.2): 31/4. The median length of hospital stay was 9 (8-15) days.
2. The en bloc resection and R0 resection rate were 94% (33/35), 83% (29/35), respectively.
3. Complications: intraoperative perforation was 8% (3/35). The intraoperative perforation site was sutured laparoscopically after ESD was completed. Intraoperative bleeding requiring blood transfusion, delayed perforation, and delayed bleeding were 0%.
4. The rate of complete closure by laparoscopy was 0% (0/26) for pancreatic side, and all of them were sutured with endo-clips and polyglycolic acid sheets. And that for non-pancreatic side was 100% (9/9).
5. Prognosis
Two cases of T1bSM2 were underwent pancreaticoduodenectomy, and there were no residual tumor and no lymph node metastasis. There has been no recurrence during twenty-eight and forty-two months after DLECS,
T1aM and T1bSM1 were followed up, and no local or metastatic recurrence was observed.

Conclusion

DLECS enabled complete closure of ulcers after ER regardless of size or location. Therefore, it is a safe and effective treatment for large SNADETs.

Introduction

Transjugular intrahepatic portosystemic shunt (TIPS) is a well-established interventional treatment for complications of portal hypertension. Post-TIPS transient or persistent acute bilirubin elevation (ABE) is common, possibly due to impairment of portal perfusion. The outcomes of patients with ABE is not clear.

Aims & Methods

This study investigates the incidence, clinical outcomes, and prognostic factors associated with ABE in cirrhotic patients undergoing TIPS. Between January 2009 and November 2022, 1,287 patients (882 men, 405 women; mean age, 52 years) were included in this retrospective analysis. ABE was defined as a total serum bilirubin level exceeding 85.5 μmol/L (5 mg/dL) within one week after TIPS. Statistical analyses included the Kaplan-Meier method, log-rank test, multivariate Cox regression, and stepwise regression.

Results

Post-TIPS ABE occurred in 67 patients (5.2%). Patients with ABE had significantly higher baseline Child-Pugh scores (8.39 ± 1.62 vs. 7.41 ± 1.54, P < 0.001) and MELD scores (13.98 ± 4.13 vs. 10.72 ± 2.99, P < 0.001). Refractory ascites as the TIPS indication was more frequent in the ABE group (17.91% vs. 7.21%, P = 0.001). ABE was associated with a significantly higher incidence of hepatic encephalopathy (HE): 62.7% vs. 38.3% at 1 year and 80.6% vs. 62.8% at 5 years (P = 0.042). During follow-up, 441 patients died, with causes including liver failure (n = 129), gastrointestinal bleeding (n = 100), sepsis (n = 16), multi-organ dysfunction (MOD) (n = 41), hepatocellular carcinoma (HCC) (n = 43), and other or unknown causes (n = 112). Survival rates were significantly lower in the ABE group: 1-year (52.2% vs. 85.2%), 3-year (34.3% vs. 68.3%), and 5-year (25.4% vs. 46.6%) (P < 0.001). Multivariate analysis identified ABE (hazard ratio [HR]: 2.09; 95% confidence interval [CI]: 1.41–3.10; P < 0.001), age (HR: 1.05; 95% CI: 1.04–1.06; P < 0.001), albumin level (HR: 0.95; 95% CI: 0.94–0.97; P < 0.001), pre-TIPS grade 4 HE (HR: 1.93; 95% CI: 1.19–3.14; P = 0.008), presence of HCC (HR: 1.81; 95% CI: 1.24–2.65; P = 0.002), baseline MELD score (HR: 1.09; 95% CI: 1.04–1.14; P < 0.001), and change in MELD score (HR: 1.08; 95% CI: 1.06–1.11; P < 0.001) as independent predictors of post-TIPS mortality.

Conclusion

AEB is not rare in cirrhotic patients undergoing TIPS and is associated with an increased risk of HE and mortality. Risk factors for post-TIPS mortality include AB, older age, higher and fluctuating MELD scores, concurrent HCC, severe pre-TIPS HE, and lower albumin levels. Early identification, close monitoring, and prompt management of complications are essential to improving clinical outcomes and reducing the risk of liver failure after TIPS.
